AS/NZS 5070.2:2008
$125.14
Siting and operation of radiocommunications facilities, Part 2: Guidelines for siting of radiocommunications facilities: VHF, UHF and SHF
Provides guidance for the siting, installation and operation of radiocommunications facilities for fixed, mobile and broadcasting services operating at frequencies above 30 MHz, which are generically known as the VHF, UHF and SHF bands. This Standard is to be read in conjunction with AS/NZS 5070.1.
Table of contents
Header
About this publication
Preface
1 Scope and general
1.1 Scope
1.2 Application
1.3 Referenced and related documents
1.3.1 Referenced documents
1.3.2 Related documents
2 Management
3 Planning and design
3.1 General
3.2 Propagation/coverage
3.3 VHF, UHF and SHF equipment
3.3.1 General
3.3.2 Interference to receivers
3.4 VHF, UHF and SHF antenna systems
3.4.1 General
3.4.2 Minimizing interference
4 Construction and installation
4.1 General
4.2 VHF, UHF and SHF antenna systems
4.2.1 General
4.2.2 Installation precautions
5 Commissioning
5.1 General
5.2 Critical VHF, UHF and SHF system parameters
6 Operation and maintenance
7 Decommissioning
Appendix A
Appendix B
B1 General
B2 Filters
B3 Receivers and receiver systems
Appendix C
C1 General
C2 Radiation pattern
C3 Cross-polar performance
C4 Voltage standing wave ratio (VSWR)
C5 Filters and multiplexers
C6 Isolation of transmitters
C6.1 General
C6.2 Ferrite circulator
C6.3 Cavity resonator
C6.4 Notch filters
C6.5 Hybrid couplers
C6.6 Multicoupling schemes
Appendix D
D1 General
D2 Types of base station
D3 Locating base station sites
D4 Antenna systems for cellular base stations
D4.1 Obstructions
D4.2 Sectorization
D4.3 Specialized antenna systems
D5 Dynamic management of cellular base stations
D6 Minimization of EMR
Cited references in this standard
Please select a variation to view its description.
| Published | 19/05/2008 |
|---|---|
| Pages | 18 |
