AS/NZS 4024.1903:2014
$149.01
Safety of machinery, Part 1903: Displays, controls, actuators and signals — Ergonomic requirements for the design of displays and control actuators — Control actuators
Adopts EN894-3:2000, which gives guidance on the selection, design and location of control actuators so that they are adapted to the requirements of the operators, are suitable for the task in question and take account of the circumstances of their use. It applies to manual control actuators used in equipment for occupational and private use.
Table of contents
Header
About this publication
PREFACE
1 Scope
2 Normative references
3 Terms and definitions
4 Selection procedure
5 Task evaluation and information collection
5.1 Requirements and characteristics
5.2 Determination of general task requirements a) to c)
5.2.1 Task requirement a: ) Classification of accuracy (accuracy)
5.2.1.1 Discrete manual control actuator movements
5.2.1.2 Continuous manual control actuator movements
5.2.2 Task requirement b): Classification of speed (speed)
5.2.3 Task requirement c): Classification of force/torque (force)
5.3 Determination of specific task requirements d) to i)
5.3.1 Task requirement d): Need for visual checking of manual control actuator setting (visual check)
5.3.2 Task requirement e): Need for tactile checking of setting (tactile check)
5.3.3 Task requirement f): Need to avoid inadvertent operation
5.3.4 Task requirement g): Need to avoid hand slipping from manual control actuator (friction)
5.3.5 Task requirement h): Need for operator to wear gloves
5.3.6 Task requirement i): Need for easy cleaning
5.4 Specification of movement characteristics
5.4.1 Movement characteristic j) linear or rotary
5.4.2 Movement characteristic k) axis of movement:
5.4.3 Movement characteristic l) direction of movement:
5.4.4 Movement characteristic m) continuity of movement:
5.4.5 Movement characteristic n) angle of rotation for continuous rotary movement > 180°:
5.5 Grip characteristics
5.5.1 Grip characteristic o) type of grip:
5.5.2 Grip characteristic p) part of hand applying force:
5.5.3 Grip characteristic q) method of applying force:
5.6 Recording the information
6 Intermediate selection of control families
7 Identification of suitable control types
8 Additional information for the design of manual control actuators
8.1 Dimensions
8.2 Actuation force or torque
8.3 Position relative to operator
8.4 Position relative to visual displays
8.5 Compatibility and consistency
Annex A
A.1 Task evaluation and information collection (Clause 5)
A.2 Intermediate selection of control family (Clause 6)
A.3 Identification of suitable control types (Clause 7)
