AS ISO 6015:2021
$125.14
Earth-moving machinery — Hydraulic excavators and backhoe loaders — Methods of determining tool forces
Identically adopts ISO 6015:2006, which specifies methods for measuring and calculating the tool forces of earth-moving attachments fitted to hydraulic excavators and the hoe equipment of backhoe loaders. It is applicable to hydraulic excavators and backhoe loaders as defined in ISO 6165. KEYWORDS: Tool forces; Hydraulic excavators; Backhoe loaders; Measurement; Calculation
Table of contents
Header
About this publication
Preface
Foreword
1 Scope
2 Normative references
3 Terms and definitions
4 Measurement methods
4.1 Test site and general
4.2 Test apparatus
4.2.1
4.2.2
4.2.3
4.2.4
4.3 Preparation for testing
4.4 Requirement during testing
4.5 Limit conditions
4.6 Pivot positions
4.7 Outriggers
4.8 Measurement procedure
4.8.1 General
4.8.2 Arm cylinder tool force
4.8.2.1 Hoe equipment
4.8.2.2 Shovel equipment
4.8.3 Bucket cylinder tool force
4.8.3.1 Hoe and telescoping boom equipment
4.8.3.2 Shovel equipment
4.8.4 Crowd tool force
4.8.5 Grab/clamshell closing force
4.9 Test report
5 Calculation methods
5.1 General
5.2 Rated tool forces and closing force
5.2.1 Arm cylinder tool force
5.2.2 Bucket cylinder tool force
5.2.3 Crowd tool force
5.2.4 Grab/clamshell closing force
6 Verification of rated tool and closing forces
Cited references in this standard
Please select a variation to view its description.
| Published | 01/04/2021 |
|---|---|
| Pages | 14 |
