AS B165: 01/01/1960 Tee slots

AS B165: 01/01/1960 Tee slots

Original price was: $47.64.Current price is: $23.20.

Tee slots 01/01/1960

PDF Format Searchable Printable Bookmarks

Specifies dimensions for tee slots for use on machine tools and auxiliary equipment, dimensions for the bolt heads to be used in the tee slots and the pitches between tee slots in machine beds. Dimensions and tolerances for tenon slots are included. The formulae on which the dimensions are generally based are also given. A complete set of dimensions for all nominal sizes is presented in the appendix, together with nearest metric dimensions.

Attributes

Edition 1st
Published 01/01/1960
Number of Pages 15
File Size 1 file, 390 KB
Product Code(s) 10112913
Note This product is unavailable in Russia, Belarus
