AS 4034.1:2024
$177.61
Motor vehicles – Cargo barriers for occupant protection, Part 1: Cargo barriers
AS 4034.1:2024 specifies a range of performance requirements including load ratings for cargo barriers and their design, installation and usage in vehicles for the protection of occupants
Table of contents
Header
About this publication
Preface
Introduction
1 Scope and general
1.1 Scope
1.2 Normative references
1.3 Terms and definitions
1.4 Configurations
1.5 Cargo barrier ratings
2 Design and installation requirements
2.1 General
2.2 Deformation
2.3 Means of escape
2.4 Anchorages
2.5 Head restraints
2.6 Seat belt clearance
2.7 Installation of child restraint systems
2.7.1 General
2.7.2 Child restraint upper-anchorage strap cut-outs
2.8 Attachments
2.9 Clearance between cargo barrier and vehicle
2.10 Frame members
2.11 Height adjustment in multi-position cargo barrier
2.12 Window in cargo barrier
2.13 Door in cargo barrier
2.14 Construction requirements
2.15 Cargo barriers for vehicles fitted with airbags
3 Performance requirements
3.1 Impact strength
3.2 Energy level for impact testing
3.3 Penetration
3.4 Glare
4 Marking
4.1 Colour of plaque or label
4.2 Information on plaque or label
4.3 Additional plaque or label
5 Packaging
5.1 General
5.2 User instructions
5.3 Installation instructions
Appendix A
A.1 Scope
A.2 Principle
A.3 Apparatus
A.4 Test specimen
A.5 Test mass position
A.6 Procedures
A.6.1 General
A.6.2 Full frontal test
A.6.3 Sled test
A.7 Report
Appendix B
B.1 Scope
B.2 Principle
B.3 Apparatus
B.4 Testing of cargo barriers based on volume manufactured
B.5 Test mass
B.5.1 General
B.5.2 Design requirements
B.6 Support frame
B.6.1 General
B.6.2 Design requirements
B.6.3 Anchorage simulation
B.6.4 Adjusting the support frame to suit a cargo barrier prior to drop testing
B.6.5 Support frame mass
B.7 Body shell
B.7.1 General
B.7.2 Preparation of partial body shell
B.8 Test specimen
B.9 Test rig
B.9.1 General
B.9.2 Release mechanism
B.9.3 Supporting structure
B.9.4 Platform
B.10 Procedure
B.11 Report
Appendix C
C.1 Scope
C.2 Principle
C.3 Apparatus
C.4 Test specimen
C.5 Test point locations
C.6 Force ram
C.7 Procedure
C.8 Report
Bibliography
Cited references in this standard
Please select a variation to view its description.
| Published | 28/06/2024 |
|---|---|
| Pages | 41 |
