AS 1528.4:2019
$125.14
Stainless steel tubes and tube fittings for food processing and hygienic applications, Part 4: Clamp tube fittings
This Standard specifies requirements for welded-type and expanded-type clamp tube fittings, comprising clamps, clamp liners (ferrules), end caps and gaskets in tube couplings for effecting joins in pipelines in food processing and hygienic applications. Requirements for materials, dimensions, and surface finish are specified.
