AS 1330:2019
$125.14
Metallic materials – Drop weight tear test for steels
This Standard specifies the method for conducting a drop weight tear test (DWTT) for carbon steel, low alloy steel, and similar materials. In particular, it applies to testing line-pipe, and strip or plate intended for line-pipe of 150 mm in diameter or greater but excludes the testing of weld metal. Where thickness is greater than 19 mm, an alternative method is permitted.
Table of contents
Header
About this publication
Preface
1 Scope
2 Normative references
3 Terms and definitions
4 Symbols and abbreviated terms
5 Apparatus
5.1 Testing machine
5.2 Anticipated fracture
5.3 Test machine setup
5.4 Tolerances
5.5 Temperature control
6 Test piece
6.1 Location of the test piece
6.2 Test piece geometry
6.3 Thickness of the test piece
6.4 Test piece preparation
6.5 Notching of the test piece
7 Test method
7.1 Test piece conditioning
7.2 Testing speed
7.3 Test piece alignment
7.4 Determination of FATT
8 Test evaluation
8.1 Results
8.2 Shear area of the fractured surface
8.3 Fracture assessment
9 Test report
10 Precision
Appendix A
Appendix B
B.1 Determination of shear area
B.2 Shear areas between 45 % and 100 %
B.3 Shear areas between 0 % and 45 %
Appendix C
Cited references in this standard
Please select a variation to view its description.
| Published | 29/10/2019 |
|---|---|
| Pages | 20 |
